Single Ball Flexible Pipe Rubber Expansion Joint Bellow
Single Ball Flexible Pipe Rubber Expansion Joint Bellow
- [Name]: Single Ball Flexible Pipe Rubber Expansion Joint Bellow
- [PN]: 0.6-2.5mpa
- [Medium]: Air, water, seawater, oil, slurry, weak acid, alkali, etc.
- [Material]: NBR, NR, CR, EPDM, PTFE
- [Certification]:ISO9001:2008
- [Products]: Flexible Expansion Joints, Pipe Expansion Joint, Rubber Expansion Joints, Bellow Expansion Joint, Rubber Bellow Joint, Pipe Rubber Joints, Flexible Rubber Joint
Single sphere flexible rubber expansion joints coupling also called Pipe Expansion Joint, Rubber Expansion Joints, Bellow Expansion Joint, Rubber Bellow Joint, Pipe Rubber Joints, Flexible Rubber Joint etc. Flexible pipe rubber coupling, is composed of inner layer, Nylon cord fabric enhancement layer,rubber sphere and metal flange. It has the characteristics of high pressure resistance, good flexiblity, big displacement, balance pipeline deviation, absorbing vibration, good effect to reduce noise, easy installation.
Product Function: unique design, simple structure and good sealing performance, flexible rubber expansion joint completely solve the pipeline displacement problems caused by thermal expansion and contraction, as well as mechanical and pipe vibration.
Bellow Expansion Joint provide a wide range of rubber support with a reinforcement that depends on the pressure required. These types of elastomeric Rubber Bellow Joint isolate noise and vibration. When it comes to damage caused by vibration and expansion, each rubber expansion joint protects pipe systems by avoiding.
Impress with Pipe Expansion Joint's compensating and damping material properties
Long service life and high operational reliability.
Single ball Flexible Rubber Joint is used in industrial environments and in plant and process engineering, as well as in mechanical engineering, building services engineering, environmental engineering and hydraulics.
Pipe Rubber Joints come in diameters from 1" to 120" and can be made with any elastomer material
Various movement requirements can be met, Non-standard designs are manufactured as required
Flexible expansion joint is of high working pressure, anti-burst and good elasticity.
|
Nominal
Diameter(DN) |
Length(mm)
|
Flange
thickness(mm) |
No. of Bolts
|
Diameter of
bolt hole (mm) |
Central diameter of bolt hole
(mm) |
Axial displacement(mm)
|
Horizontal
displacement (mm) |
Angular
deflection(a1+a2) |
||
|
mm
|
Inch
|
Extension
|
Compression
|
|||||||
|
32
|
1.25
|
95
|
16
|
4
|
18
|
100
|
6
|
9
|
9
|
15
|
|
40
|
1.5
|
95
|
18
|
4
|
18
|
110
|
6
|
10
|
9
|
15
|
|
50
|
2
|
105
|
18
|
4
|
18
|
125
|
7
|
10
|
10
|
15
|
|
65
|
2.5
|
115
|
20
|
4
|
18
|
145
|
7
|
13
|
11
|
15
|
|
80
|
3
|
135
|
20
|
4
|
18
|
160
|
8
|
15
|
12
|
15
|
|
100
|
4
|
150
|
22
|
8
|
18
|
180
|
10
|
19
|
13
|
15
|
|
125
|
5
|
165
|
24
|
8
|
18
|
210
|
12
|
19
|
13
|
15
|
|
150
|
6
|
180
|
24
|
8
|
23
|
240
|
12
|
20
|
14
|
15
|
|
200
|
8
|
210
|
24
|
8
|
23
|
295
|
16
|
25
|
22
|
15
|
|
250
|
10
|
230
|
26
|
12
|
23
|
350
|
16
|
25
|
22
|
15
|
|
300
|
12
|
245
|
28
|
12
|
23
|
400
|
16
|
25
|
22
|
15
|
|
350
|
14
|
255
|
28
|
16
|
23
|
460
|
16
|
25
|
22
|
15
|
|
400
|
16
|
255
|
30
|
16
|
25
|
515
|
16
|
25
|
22
|
15
|
|
450
|
18
|
255
|
30
|
20
|
25
|
565
|
16
|
25
|
22
|
15
|
|
500
|
20
|
255
|
32
|
20
|
25
|
620
|
16
|
25
|
22
|
15
|
|
600
|
24
|
260
|
36
|
20
|
30
|
725
|
16
|
25
|
22
|
15
|
|
700
|
28
|
260
|
36
|
24
|
30
|
840
|
16
|
25
|
22
|
15
|
|
800
|
32
|
260
|
38
|
24
|
34
|
950
|
16
|
25
|
22
|
15
|
|
900
|
36
|
260
|
42
|
28
|
34
|
1050
|
16
|
25
|
22
|
15
|
|
1000
|
40
|
260
|
44
|
28
|
34
|
1160
|
18
|
26
|
24
|
15
|
|
1200
|
48
|
260
|
48
|
32
|
41
|
1380
|
18
|
26
|
24
|
15
|
|
1400
|
56
|
350
|
44
|
36
|
34
|
1560
|
20
|
28
|
26
|
15
|
|
1600
|
64
|
350
|
46
|
40
|
34
|
1760
|
25
|
35
|
30
|
10
|
|
1800
|
72
|
350
|
52
|
44
|
41
|
1976
|
25
|
35
|
30
|
10
|
|
2000
|
80
|
350
|
54
|
48
|
48
|
2180
|
25
|
35
|
30
|
10
|
|
2200
|
88
|
350
|
40
|
52
|
48
|
2390
|
25
|
35
|
30
|
10
|
|
2200
|
88
|
400
|
40
|
52
|
48
|
2390
|
25
|
35
|
30
|
10
|
|
2400
|
96
|
400
|
41
|
56
|
48
|
2600
|
25
|
35
|
30
|
10
|
|
2600
|
104
|
400
|
42
|
60
|
54
|
2810
|
25
|
35
|
30
|
10
|
|
2800
|
112
|
400
|
45
|
64
|
54
|
3020
|
25
|
35
|
30
|
10
|
|
3000
|
120
|
400
|
50
|
68
|
54
|
3220
|
25
|
35
|
30
|
10
|
