GDT type pipe elastic bracket shock absorber

 Features of GDT type pipe elastic bracket shock absorber:

GDT type pipe elastic bracket shock absorber is local pasted by the arced concave-convex elastic rubber pad and arced metal. Generally used in installation of pipeline vibration isolation for mechanical equipment, also applicable for the installation of pipe supports, through-wall, ceiling and other installation, from the pipe spread way to control vibration transmission, and improve the environment.

The elastic rubber pad has three kinds of rubber hardness,deformation amount is 3-8mm under loading , static force and deformation relation is linear, stiffness increase with loading. Natural frequency: single 10Hz-12Hz; double 8Hz-11Hz.

For relatively large pipe vibration or places for high vibration performance requirements, multilayer elastic rubber pads can be used in tandem, each layer between the elastic rubber isolated with a arced metal plate. Products can work at temperature of -10 ° C-50 ° C.
